GW Series pneumatic actuatorApplicable gas source: 0.3 ~ 0.7MPaRotation angle: 0 ° ~ 90 °Working hydraulic pressure: 20MPaAir source interface: meet nrmar standardOutput torque: double acting 616 ~ 396139n. M, single acting (spring output torque) 604 ~ 163638n. MAction form: single action and double actionAmbient tempe...
Motor power supply: 110 / 220V AC 1PH, 380 / 440V AC 3Ph, 50 / 60Hz, ± 10%Control power supply: 110 / 220V AC 1PH, 50 / 60 Hz, ± 10%Motor type: squirrel cage asynchronous motorLimit switch: 2 x on / off, SPDT, 250V AC 10AAmbient temperature: - 20 ℃ ~ + 70 ℃Input signal: 4 ~ 20mA, or 0 ~ 10dvcOutput signal: 4 ~ 20mA, or...
Product model: QYDriving power supply: AC-DC24V, AC220V, AC380VControl signal: 0-10VDC or 4-20mAStandard time / torque: 30s / 100N. M, 30s / 160n. MRotation angle: 0-90 ° adjustableAmbient temperature: - 20 ℃ ~ + 60 ℃Protection grade: IP67 (optional IP68)Installation method: 360 ° arbitrary angle installationOptional f...
Output torque: 1000-1000000nm (5.0bar double acting)Interface size: 1 / 2 "- 1", meeting the characteristics of fast opening and fast closingRotation angle: 90 ° ~ ± 5 °Ambient temperature: - 20 ℃ ~ 90 ℃Air source pressure: 0.2 ~ 0.8MPa (maximum 1.0MPa)PRODUCT OVERVIEWAW series pneumatic actuators are divided...
AT series pneumatic actuatorTorque range: 10N. M-10000N. MTravel range: 0 ° to 90 °. Adjustable + 5 ° to - 5 °Applicable temperature: - 20 ° C to + 80 ° C (NBR)Working medium: air (pneurop / ISO level 4)Protection grade: IP67Connection size: ISO 5211 DIN 3337 coupling (star)Control mode: double acting, single acting no...
Model: H44W / H / YNominal diameter: NPS 2 "~ 24"Nominal pressure: CL150 ~ 2500 LbWorking temperature: -196 ℃ ~ + 560 ℃Main material: carbon steel, stainless steel, alloyDesign criteria: API603M, ASME B16.34, API6DConstruction Length: ASME B16.10Connection Standards: ASME B16.5, ASME B16.25Pressure Test: API...
Product: Pneumatic Rigid Sealing Flange Butterfly ValveModel: D643HNominal diameter: DN50 ~ 800mmNominal pressure: 16,25,40 barMedium temperature: W1: -40 ~ 180 ℃, W3: -30 ~ 425 ℃, W4: -40 ~ 425 ℃Body material: Carbon (C), stainless steel (P4, P6)Connected mode: flangeTemperature: standard: -20 ~ 80 ℃Design criter...
API Swing Check Valve H44H Product overviewProduct model: H44HNominal diameter: NPS1/2"~60" (DN15~1500mm)Nominal pressure: Class150~2500Lb (PN10~420MPa)Link: RF, RTJ, BWOperating temperature: -196℃~+560℃Main material: carbon steel, stainless steel, alloy steelDesign standard: API603M, ASME B16.34, A...
Electric Telescopic Butterfly Valve SD943HProduct overviewProduct model: SD943HNominal diameter: DN50~2000mmNominal pressure: PN0.6~1.6MPaApplicable medium: water, oil, gas and weak corrosive liquidsApplicable temperature: -30~200℃Operation mode: manual, worm and worm gear drive, gas drive, electric driveDesign and man...
Pneumatic Three-way Ball Valve Q644FProduct overviewModel: Q644FNominal diameter: DN15 ~ 200mmNominal pressure: PN1.6 ~ 4.0MPaOperating temperature: PTFE≤150 ℃ PTL≤300 ℃Medium: C: water, oil and gas; P: nitric acid; R: acetic acid classMain material: WCB, CF8Design specifications: GB / T 12237 API 6D API 608 BS 5351Str...
Fluorine Lined Globe Valve J41F4Product overviewProduct model: J41F4Nominal diameter: DN15~300mm NPS1"~12"Nominal pressure: PN1.0~2.5MPaApplicable temperature: -50~150℃Design specification: GB/T 12233 GB/T 12235Structure length: GB/T 12221Connection flange: JB/T 78 JB/T 79Test and inspection: GB/T...
Electric Fluorine Lined Ball ValveQ941F46-16CProduct overviewProduct model: Q941F46-16CNominal diameter: DN15 ~ 400mmNominal pressure: PN1.0 ~ 2.5MPaConnection type: flange connectionDriving device: electric actuatorApplicable medium: sulfuric acid, hydrofluoric acid, phosphoric acid, chlorine gas, strong alkali,...
Pneumatic Fixed Ball Valve Q647FProduct overviewProduct model: Q647FNominal diameter: DN50~500mmNominal pressure: PN1.6~6.4MPaApplicable temperature: -28℃ ~ 300℃Applicable medium: water, steam, oil, nitric acid, acetic acidDrive mode: manual, pneumaticStructure length: GB1221-89Flange size: GB9113, JB79-59Inspection te...
[Please Use PC or Tablet to browse products parameters]Large Caliber Metal Hard Seal Butterfly Valve D343H/Y Product overviewProduct model: D343H/YNominal diameter: DN50 ~ 2000mmNominal pressure: PN0.6~4.0MPaApplicable temperature: -40℃ ~ 570℃Applicable medium: water, oil, steam, gas, acid, alkali, etcMa...
Equipped With Eccentric Half Ball Valve DYQ40Product overviewProduct model: DYQ40Nominal diameter: DN100~1400mmNominal pressure: PN1.0~1.6MPaMain material: carbon steel WCB/ stainless steel CF8Applicable medium: natural gas, coal gas, liquefied petroleum gas, crude oil, heavy oilApplicable temperature: ≤425℃Flange...
